NEQXUS Air Treatment QX ENERGIE SAVING REFRIGERATED AIR DRYER.

All QX models feature a precooler/reheater,  demister, potential - free contact for transmission of fault messages and electronic level controlled condensate drain. Designed to remove water from your air lines, these dryers help extend tool life and eliminate flaws in paint or finishes. Plus, with better air quality, maintenance intervals and the service life of more expensive pneumatic equipment such as CNC and packing machines can also be extended.
Refrigerated Compressed Air Dryer


MODEL QX 21 R - QX 4880 R WITH INNOVATIVE HOT GAS BY-PASS VALVE.


NEQXUS Air Treatment improves it's range of compressed air dryers with the QX series (Aluminium Cooling Technology), focused to reduce energy consumption. Main features are:

  • low pressure drop even with load variances
  • low power consumption thanks to the ALU-DRY heat exchanger
  • high efficiency compressors,
  • innovative hot gas by-pass valve
  • potential -free contact
  • electronic level controlled condensate drain (all Modells)
  • constant pressure Dew Point with differing load conditions

THE ENERGY SAVING DRYER THE EVOLUTION OF THE QX NEQXUS Air Treatment SERIES.


NEQXUS Air Treatment has released the full range of QX/RC and QX/VS Energy Saving dryers. This new range comes from the need to match compressed air treatment quality with energy saving.

The new range uses the design characteristics of the QX series, which are already appreciated by the compressed air industry market, combined with innovative solutions focused to reduce the electric consumption



frequency controlled air dryer

GOOD REASONS TO CHOOSE A QX RC/RV ENERGIE SAVING DRYER.


The dimensioning of the dryer is carried out under consideration of the most unfavourable operating conditions, only this way a constant pressure dew point can be guaranteed. The dryer is calculated on the basis of the maximum flow rate, load changes are not taken into account and the maximum ambient and compressed air temperatures are also taken as a basis.

Designed for the highest ambient temperatures in summer, the refrigerant dryer is over-dimensioned most of the year and consumes correspondingly more energy.

The new technology automatically adapts to the actual cooling quantity required, thus considerably reducing operating costs.
Take a look at our products.
Please click below to see full catalogue
    and technical datas
How To Buy
NEQXUS products are made available through authorized Distributors.
These Distributors have been trained to specify, sell, install, and service the entire NEQXUS Air Treatment  product line.
To get the name of your local NEQXUS distributor or to inquire about a NEQXUS product or technology, please complete and submit the NEQXUS Contact Form.
Our company prides itself on its excellent customer service. We offer individual planning of your project and professional execution with regular updates.
