MODEL QX 21 R - QX 4880 R WITH INNOVATIVE HOT GAS BY-PASS VALVE.

NEQXUS Air Treatment improves it's range of compressed air dryers with the QX series (Aluminium Cooling Technology), focused to reduce energy consumption. Main features are:

• low pressure drop even with load variances
• low power consumption thanks to the ALU-DRY heat exchanger
• high efficiency compressors,
• innovative hot gas by-pass valve
• potential -free contact
• electronic level controlled condensate drain (all Modells)
• constant pressure Dew Point with differing load conditions

THE ENERGY SAVING DRYER THE EVOLUTION OF THE QX NEQXUS Air Treatment SERIES.

NEQXUS Air Treatment has released the full range of QX/RC and QX/VS Energy Saving dryers. This new range comes from the need to match compressed air treatment quality with energy saving.

The new range uses the design characteristics of the QX series, which are already appreciated by the compressed air industry market, combined with innovative solutions focused to reduce the electric consumption

GOOD REASONS TO CHOOSE A QX RC/RV ENERGIE SAVING DRYER.

The dimensioning of the dryer is carried out under consideration of the most unfavourable operating conditions, only this way a constant pressure dew point can be guaranteed. The dryer is calculated on the basis of the maximum flow rate, load changes are not taken into account and the maximum ambient and compressed air temperatures are also taken as a basis.

Designed for the highest ambient temperatures in summer, the refrigerant dryer is over-dimensioned most of the year and consumes correspondingly more energy.

The new technology automatically adapts to the actual cooling quantity required, thus considerably reducing operating costs.
